# Welcome/Important Links

Page ID: welcome
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=welcome
Section: getting-started
Parent ID: None
Tags:
Owner: Andre Boufama
Updated: 2026-09-18T18:28:14.411Z

This is CUPI's internal knowledge base.

Google drive: https://drive.google.com/drive/folders/1Pprdox7-1XIkVTlhPJmqW0eYzjsd9rtB

Github: https://github.com/Cornell-Physical-Intelligence

![Crab on the beach](/welcome-crab.png)

::: tip Write it down
Anything that is important should be written down here, NME, project notes, etc.

Press **N** anywhere and pick a template.

:::


---

# Mech Onboarding - Onshape Standards

Page ID: mech-onboarding-onshape-standards
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=mech-onboarding-onshape-standards
Section: mechanical
Parent ID: None
Tags:
Owner: Andre Boufama
Updated: 2026-09-18T19:17:18.196Z

Our club has the Onshape Enterprise Plan at this link: https://cupi.onshape.com/

As a member of the mechanical subteam, you will be expected to work on projects end to end using the Onshape cad software. Onshape is unique as a software in how it runs on web, and enables real time collaboration.

The parametric modeling part of Onshape is easy to adjust to (assuming you've used any other sort of CAD software), but it's more important to understand how Onshape internally organizes documents and files to properly execute on projects.

**These videos are required viewing** (you'll save a lot of time understanding Onshape's quirks if you watch them):

https://www.youtube.com/watch?v=XzX31igeTj8

https://www.youtube.com/watch?v=cyQXmb0k8H4


## Document Structure Rules

When working on a large multi month project, it's important to adhere to strict standards.

First, when starting a new project, there will be a high level project folder which contains all project documents. Inside this will be a main document with all the assemblies and part studios.

Every folder, document, part studio, etc. must be named in all capital letters.

Assemblies must be named: "[Assembly Name] ASSY"
Subassemblies must be named: "[Subassembly Name] SUBASSY"

When there are a lot of tabs (part studios/assemblies), it can be helpful to create folders to reduce clutter on the top level view.


![Screenshot 2026-08-20 at 2.51.22 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-hc0g89yumt1vtxhp "")


## Importing COTS Parts

All off the shelf parts (parts not custom designed by CUPI) must be imported into the shared "COTS PARTS" folder in their respective part category subfolder.

When importing a COTS part, make a new document for the part and title it properly based off its unique identifiers. Use this name for the document, part studio, and parts within the part studio.

**Assign a material, part number (right click to properties) and manufacturer. Also pick an appearance color that reflects the actual part. **

![Screenshot 2026-08-20 at 3.02.45 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-d5yqsvc1mt1w191p "")

![Screenshot 2026-08-20 at 3.03.02 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-9xvut0clmt1w1l3r "")

When done, **make a version in the left tab**, and you should be able to see your versioned part when importing parts into an assembly from any other document.

Versioning is EXTREMELY IMPORTANT as it allows a document to reference a cached version of a tab instead of loading the live tab which is constantly being updated. When there are upwards of 100 COTS parts in a document, this drastically reduces load times.

![Screenshot 2026-08-20 at 3.04.06 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-enhzr1scmt1w305y "")




---

# Login + Auth Info

Page ID: login-auth-info
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=login-auth-info
Section: getting-started
Parent ID: None
Tags:
Owner: Andre Boufama
Updated: 2026-08-23T20:16:42.247Z

All club hosting services, VMs, and org level login info lies here. This document is crucial during handoff so services can be properly maintained.



## [Squarespace](https://www.squarespace.com/)

Person: Andre
Login Email: andre.boufama@gmail.com

Affected Platforms:
- All domains owned by club



## [Github Org](https://github.com/Cornell-Physical-Intelligence)
Person: Andre
Login Email: andre.boufama@gmail.com

Affected Platforms:
-[ CUPI Main Website](https://github.com/Cornell-Physical-Intelligence/General-Website)


## [Vercel Pro](https://vercel.com/)
Person: Andre
Login Email: andre.boufama@gmail.com (linked to gmail and personal github)

Affected Platforms:

- Team Manager (depricated)
- CUPI WIKI

## [Resend](https://resend.com/)

Person: Andre
Login Email: andre.boufama@gmail.com

Affected Platforms:
- CUPI WIKI

## [Google Cloud Console ](https://console.cloud.google.com/)

Person: Andre
Login Email: andre.boufama@gmail.com

Affected Platforms:
- CUPI WIKI
- CUPI Main Website

Notes: This is where a lot of the SEO is done for surfacing our site on google.




---

# Software Onboarding - Repo Standards

Page ID: software-onboarding-repo-standards
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=software-onboarding-repo-standards
Section: software
Parent ID: None
Tags:
Owner: James Cenawood
Updated: 2026-09-11T01:10:57.178Z

Our code lives at [github.com/Cornell-Physical-Intelligence](https://github.com/Cornell-Physical-Intelligence). Ask one of the software leads for org membership. Our main current project is the hexapod. The MKII hexapod repo is `hexapod-cupi`.

As a member of the software subteam, you will work end-to-end in a repo: environment, code, tests, PR. Isaac Sim is never required on your laptop. The test suite and the viewer run locally; training runs on the shared DGX Spark, and you get Spark access from the project lead after you finish this page.

## Required before your first PR

These are required before your first PR (they will save you and your reviewer a lot of time):

**Python Tutorial: UV - A Faster, All-in-One Package Manager** (Corey Schafer, YouTube)

https://www.youtube.com/watch?v=AMdG7IjgSPM

- **UV: First Steps** (Astral docs) [Open ↗](https://docs.astral.sh/uv/getting-started/first-steps/)

**Mastering Claude Code in 30 Minutes** (Anthropic, YouTube)

https://www.youtube.com/watch?v=AOfogJZ70OQ

- **Claude Code Quickstart** (Anthropic docs) [Open ↗](https://code.claude.com/docs/en/quickstart)


Then read `README.md`, `CLAUDE.md`, and `docs/ONBOARDING.md` in `hexapod-cupi`, in that order. `CLAUDE.md` holds the project invariants and agent directions.

## Environment Rules

uv is the package manager for every Python repo. Do NOT use pip, conda, or `python -m venv` directly. Every repo must have a `pyproject.toml` and a committed `uv.lock`. Setup is one command, `uv sync`, and every script runs through `uv run`, for example, `uv run python -m unittest discover -s isaaclab/tests`. Adding a dependency is `uv add [package]`, which updates both files; commit them together. The lockfile is what makes your test run and the DGX Spark's test run the same.

## Repo Rules

Every repo must have a `README.md` that opens with one paragraph saying what the repo is and where to start. Branches are named `[netid]/[task]`, for example `jd632/height-scan-validator`. Every change goes through a PR to `main`, and CI must be green before merge. Do NOT commit secrets, checkpoints, or anything under `artifacts/` outside Git LFS.

## Claude Code Rules

Claude Code is the standard agent for this team, and every repo carries a `CLAUDE.md` at its root; the agent reads it on every session, so a rule written there is a rule the agent follows. Run it from the repo root so it picks that file up. You do not have to manually review everything it produces before you commit it, but the PR is yours, so a change you cannot explain does not go in. You must be comfortable with ownership over it. Do NOT paste secrets, Spark paths with credentials, or `.env` contents into a session.

## Setting Up

```sh
git clone https://github.com/Cornell-Physical-Intelligence/hexapod-cupi.git
cd hexapod-cupi
uv sync
uv run python -m unittest discover -s isaaclab/tests
cd viewer && npm install && npm run dev
```

Read the test count off the run. Confirm the robot renders in the viewer at ex. `http://localhost:5173`.

## Results Standard

Training is random, so a trained policy is a specific file of weights (in this repo a `model_N.pt` checkpoint), and a speed or gait number belongs to that file. Every checkpoint you report is recorded with its SHA-256 hash, the fingerprint of the file's bytes (`sha256sum model.pt`), so that anyone can confirm they are re-testing the same weights. A number without a hash, the evaluation output, and the exact test settings is a note, and it does not go in a table or a commit message as a result.

The test settings include the playback limiter: the cap on how far a joint target may move per 20 ms tick before it reaches the motors. Every formal measurement in the repo uses `0.040 rad` per tick. A looser limiter lets the same policy walk faster, so numbers taken at different limiters are answers to different questions and must NEVER share a table.


---

# Software Onboarding - Locomotion (RL)

Page ID: software-onboarding-locomotion-rl
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=software-onboarding-locomotion-rl
Section: software
Parent ID: None
Tags:
Owner: James Cenawood
Updated: 2026-09-04T14:35:03.507Z

Finish [[Software Onboarding - Repo Standards]] first. The locomotion code lives in `packages/hexapod_env` (environment, `rewards/`, stage configs, gym registration), `packages/hexapod_train` (run composition), `packages/hexapod_eval` (the acceptance gates in `gates.py`), and `configs/` (named experiment baselines and intervention deltas). Every reward term and every launcher contract has a test under `isaaclab/tests/`.

Isaac Lab runs thousands of copies of the robot in parallel on one GPU. Each copy steps the physics. One neural network, the policy, reads each robot's joint positions, velocities, and body orientation and outputs 18 joint targets at 50 Hz. PPO updates the network so that actions which earned more reward than expected become more likely, with a clip on how far the policy may move per update. The reward is a sum of hand-written terms (forward speed tracking, yaw penalty, deck height, torque limits). Most locomotion work on this team is editing those terms and the curriculum that schedules them. You edit and test on your laptop and launch on the Spark.

These are required before your first training attempt:

PROXIMAL POLICY OPTIMIZATION (OpenAI Spinning Up)
[Open ↗](https://spinningup.openai.com/en/latest/algorithms/ppo.html)

LEARNING TO WALK IN MINUTES USING MASSIVELY PARALLEL DEEP RL (Rudin et al., 2022, the paper this recipe descends from)
[Open ↗](https://arxiv.org/abs/2109.11978)

CREATING A DIRECT WORKFLOW RL ENVIRONMENT (Isaac Lab docs, `DirectRLEnv` is the class our task subclasses)
[Open ↗](https://isaac-sim.github.io/IsaacLab/main/source/tutorials/03_envs/create_direct_rl_env.html)

RSL-RL (the PPO implementation we train with)
[Open ↗](https://github.com/leggedrobotics/rsl_rl)

Then read `docs/TRAINING.md` in full. It holds the observation layout, the reward terms, the curriculum stages, and the acceptance gates in §6.

## Attempt Rules

One training run is one attempt. Every attempt has a unique label that names its experiment file, intervention file, and seed, for example `stage2c_yawpen160_seed86`. A label is used once. A failed attempt keeps its label and its directory. Attempts are launched from the shared queue in `docs/ROADMAP.md` §7, through `ops/hexctl`, after `ops/hexctl doctor` passes. One GB10 runs one Isaac Sim job well. An unlisted launch can stall someone else's.

## Task ID and Gate Rules

Gym task IDs in `packages/hexapod_env/hexapod_env/register.py` are frozen. Checkpoints, launchers, and evaluation payloads reference them by string, so renaming an ID orphans every checkpoint trained under it. A new task gets a new ID. The gates in `docs/TRAINING.md` §6 and `gates.py` are written before the work starts and stay fixed. A checkpoint that misses a gate is a candidate.

## Results Standard

Every formal screen uses seed 60, 10 s / 475 samples, commands stand / 0.16 / 0.20 / 0.30 m/s, and the `0.040 rad / 20 ms` playback limiter. The limiter caps how far a joint target may move per tick before it reaches the motors, and a looser cap lets the same policy walk faster. A speed measured at another limiter must NEVER be placed in the same table. The current best checkpoint, its hash, and its screen numbers live in `STATUS.md` only.


---

# Software Onboarding - ROS 2 (Perception and Navigation)

Page ID: software-onboarding-ros-2-perception-and-navigation
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=software-onboarding-ros-2-perception-and-navigation
Section: software
Parent ID: None
Tags:
Owner: James Cenawood
Updated: 2026-09-04T14:34:36.880Z

Finish [[Software Onboarding - Repo Standards]] first. Perception and navigation code lives under `ros2_ws/` in three packages: `hexapod_perception` (Livox driver bring-up, lidar-inertial odometry, elevation and global maps), `hexapod_msgs` (message definitions for contracts C2, C3, and C4), and `hexapod_bringup` (launch files and parameter sets). `ros2_ws/` is created in milestone M0. If it does not exist yet, creating it is the first task.

We use ROS 2 Jazzy on Ubuntu 24.04. Jazzy is a long-term-support release (supported through May 2029) and every package we depend on (`livox_ros_driver2`, the FAST-LIO ROS 2 branch, the ROS 2 elevation mapping port) supports it. On macOS or Windows, work inside a Jazzy Docker container. This workstream runs on laptops and the bench computer and stays off the Spark GPU.

A running ROS 2 system is a graph of separate processes called nodes that exchange typed messages on named topics. The driver node publishes point clouds, the odometry node subscribes to them and publishes a pose, the mapping node subscribes to both. Coordinate frames are tracked by `tf2`, so every message carries a frame id and a timestamp. Every session is recorded to a bag file, and the team tests on bags before hardware.

These are required before your first PR:

ROS 2 JAZZY TUTORIALS: BEGINNER CLI TOOLS, THEN BEGINNER CLIENT LIBRARIES (official docs)
[Open ↗](https://docs.ros.org/en/jazzy/Tutorials.html)

LIVOX ROS DRIVER 2 (the Mid-360 driver)
[Open ↗](https://github.com/Livox-SDK/livox_ros_driver2)

FAST-LIO, ROS 2 BRANCH (lidar-inertial odometry, Point-LIO is the alternative)
[Open ↗](https://github.com/hku-mars/FAST_LIO/tree/ROS2)

ELEVATION MAPPING ON GPU FOR ROS 2 (Humble/Jazzy port of `elevation_mapping_cupy`)
[Open ↗](https://github.com/iit-DLSLab/elevation_mapping_gpu_ros2)

Then read `docs/ARCHITECTURE.md` §2 and §4. The policy consumes a height grid, perception produces poses and maps, and navigation produces velocity commands. Those three sentences decide which package you may edit.

## Package Rules

ROS 2 code lives under `ros2_ws/`. Do NOT import `rclpy` or any ROS package from `packages/`. The training container and the bare-interpreter test suite run without ROS installed. Message definitions in `hexapod_msgs` are contracts. Once a contract is versioned it is frozen, and a change is a new message version published beside the old one. Every message carries a header with a stamp and a frame id. Frames are named `odom` for odometry and `map` for the global map.

## Bag Rules

Every bench or field session is recorded with `ros2 bag record` and named `[YYYYMMDD]_[location]_[sensor]_[netid]_[n]`, for example `20260912_upson-hall_mid360_jd632_01`. Handheld loops start and end at the same surveyed point so odometry drift can be measured.

## A First Bench Session

Confirm the sensor identity from the physical label first (the identification gate in `robot/sensors/README.md`). Power the Mid-360, launch `livox_ros_driver2`, and check the stream with `ros2 topic hz` on the point cloud and IMU topics. Record a two-minute handheld loop with `ros2 bag record -a`, name it per the scheme, and replay it into the LIO launch file. The session is done when the replayed pose returns to the starting point and the elevation map publishes at 10 Hz.

## Contract Standard

Contract C2, the local height scan the policy consumes, is published at 50 Hz with a timestamp, and the runtime refuses a scan older than the contract's max age. A correct map that arrives late fails the contract, so measure latency on every change and record it with the bag it was measured on.


---

# Elec Reference - PCB Design Practices

Page ID: elec-reference-pcb-design-practices
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=elec-reference-pcb-design-practices
Section: electrical
Parent ID: None
Tags:
Owner: Nathan Cunningham
Updated: 2026-09-14T20:52:22.710Z

::: tip How to Use this Document
Reference this document while working in the schematic design phase of PCB development.

Whenever unsure about when/how to implement a component, never guess. Assumptions can secretly kill the board's performance, so always check your work with this document and other tools.
:::

## Navigation

- Design Heuristics
- Common Pitfalls
- Key Components
 - Protection and Reliability
 - Signal Stability and Digital Logic
 - Power Supply
 - Transistor and Switching
 - Inductive Load and Motors
 - Analog and Sensor Interface
 - Communication Interface
 - Useful Learning Materials

## Design Heuristics
**Power Distribution & Power Integrity**
- Put decoupling capacitors close to IC power pins: Long traces add inductance and make the capacitor ineffective at high frequency
- Transmit power at higher voltage and lower current when practical: Reduces RI² losses, conductor size, and voltage drop
- Keep high-current paths short and wide: Reduces resistance, heating, voltage drop, and inductance
- Use LDOs when simplicity and low noise matter and the voltage drop/current are modest: They trade efficiency for simplicity and low noise
- Check effective capacitance of capacitors; DC bias can cause a much lower capacitance than expected, especially with low-capacitance X7R caps
- Put bulk capacitance near large transient loads: Supplies slower, larger bursts of current locally
- Add lots of test points for regulator I/O, important power rails, and ground

**Grounding, EMI, & Noise Control**
- Keep high-frequency current loops physically small: Reduces parasitic inductance and radiated EMI
- Give every high-speed signal a nearby return path: Current always travels in a loop; poor return paths increase EMI and signal-integrity problems
- Use a solid, continuous ground plane whenever practical: Creates low-impedance return paths and improves signal integrity. It is extremely highly recommended to avoid routing on or creating voids in the ground planes for> 2-layer boards
- Avoid unnecessary splits in ground planes: High-speed return current may otherwise be forced into a large loop. Keep analog and digital grounds as a common ground unless you have a reason to do otherwise.
- Place ground stitching vias where useful: Connects ground planes together to reduce impedance and improve EMI performance
- Surround RF/noisy circuitry with a via fence when appropriate: Reduces electromagnetic coupling
- Physically separate sensitive analog circuitry from noisy switching circuitry: Reduces conducted and radiated interference
- Keep switching nodes physically small: Fast dV/dt nodes capacitively couple noise into neighboring circuitry
- Locate filtering near the noise source: Prevents noise from propagating through the board

**Signal Integrity & Communication**
- Prefer differential signaling for high-speed or noisy environments: Improves rejection of common-mode noise and can reduce EMI
- Avoid routing high-speed signals near board edges: Reduces susceptibility to interference and unwanted radiation
- Keep differential pairs together and geometrically similar: Preserves differential impedance and minimizes skew
- For high-speed signals, ensure a gap of 3x the trace width between traces (generally, can vary) - reduces crosstalk between lines
- Minimize vias on critical high-speed signals: Vias introduce impedance discontinuities and parasitic inductance/capacitance
- Prefer serial over parallel communication for longer-distance data transmission when practical: Fewer conductors and fewer timing/skew issues; use multiplexing when appropriate
- Voltage-based systems generally want high input impedance and low output impedance; current-based interfaces generally follow the opposite principle
- Route high speed signals over ground planes, AC signals best return path is parallel to the forward path. Any blocks in that path will cause EMI
- Always check an IC pins idle states and signal direction to properly make use of pull up / down resistors.


**Protection & Robustness**
- Put protection components close to the input/connector: Stop ESD and transients before they travel across the PCB
- Use pull-ups/pull-downs whenever a digital signal could otherwise float: Floating CMOS inputs can randomly switch and consume excess current
- Don't leave MOSFET gates floating: The gate stores charge and can turn the transistor on unpredictably

**Debugging, Testability, & Configuration**
- Implement test points for oscilloscope probes, multimeters, programming, and debugging
- Include status LEDs for verifying power rails, communication, boot state, or GPIO activity
- Use a 0 Ω resistor where you may want to disconnect or reroute a connection during debugging/testing
- Use a jumper/shunt header to manually connect selected nodes: Useful for selecting operating modes, addresses, power sources, etc.
- Use a solder jumper as a compact, inexpensive way to manually select PCB configurations



## Common Pitfalls

- Overcurrent: More current flows through a component or trace than intended
- Overvoltage: A node exceeds its allowable voltage
- Parasitics: Unwanted resistance, capacitance, and inductance from traces, vias, packages, etc.
- Undervoltage: Supply voltage falls below what the IC needs
- Voltage transients: Very brief voltage spikes/dips
- Reverse polarity: Power is connected backward
- ESD: Static discharge enters through connectors, buttons, exposed conductors, etc.
- Ground bounce: Current changes create voltage differences across supposedly common ground
- Poor return paths: Signal current cannot flow directly beneath or beside its outgoing trace
- Inadequate decoupling: IC cannot obtain transient current locally
- Crosstalk: One trace electromagnetically couples into another
- EMI: Board generates or receives electromagnetic interference
- Floating inputs: Digital or analog input has no defined voltage
- Bus contention: Two outputs try to drive the same line to opposite states
- Back-powering: Current enters an unpowered IC through an I/O pin



## Key Components

**Protection & Reliability**
| | |
| --- | --- |
| Flyback diode | Suppresses the large voltage spike produced when an inductive load like a relay, motor, or solenoid is switched off |
| Reverse-polarity protection | Prevents damage if the power supply is connected backward; commonly implemented with a diode or MOSFET |
| Schottky diode | Useful for low-voltage-drop protection, clamping, power OR-ing, and flyback suppression |
| TVS diode | Absorbs short, high-energy voltage transients from ESD, cables, automotive supplies, etc. |
| Zener diode clamp | Limits a node to approximately a chosen maximum voltage |
| ESD protection diode array | Protects USB, UART, CAN, buttons, connectors, and other exposed signals against static discharge |
| Fuse | Permanently disconnects power during excessive current |
| Resettable fuse/PTC | Limits current during a fault and automatically recovers after the fault is removed |
| Crowbar protection | Intentionally shorts the supply through an SCR/MOSFET when dangerous overvoltage occurs, usually blowing a fuse |
| Ideal-diode MOSFET | Performs diode-like reverse-current/reverse-polarity protection with much lower voltage loss |
| Current-limiting resistor | Protects LEDs, GPIOs, transistor bases, and other components from excessive current |
| Series protection resistor | Limits fault/ESD current entering an IC pin and can also reduce signal ringing |

**Signal Stability and Digital Logic**
| | |
| --- | --- |
| Pull-down resistor | Forces a signal LOW when nothing actively drives it |
| Pull-up resistor | Forces a signal HIGH when nothing actively drives it; essential for open-drain buses such as I²C |
| Series termination resistor | Reduces ringing and reflections on fast digital traces; often placed near the driving IC |
| RC debounce circuit | Filters mechanical switch bouncing before a button signal reaches digital logic |
| Schmitt-trigger buffer | Converts noisy or slowly changing signals into clean digital transitions |
| Voltage divider | Scales down voltages for ADCs, sensing circuits, reference generation, etc. |
| Logic-level shifter | Safely interfaces devices using different logic voltages, such as 5 V and 3.3 V |
| Open-drain / open-collector output | Allows multiple devices to safely share a line and is useful for wired-AND signaling |
| Weak pull-up/down + strong driver | Establishes a default state while still allowing an active device to override it easily |
| Unused-input biasing | Ties otherwise floating CMOS inputs HIGH or LOW so they do not randomly switch |

**Power Supply**
| | |
| --- | --- |
| Decoupling capacitor | Supplies very short bursts of current directly beside an IC and suppresses high-frequency supply noise |
| Bulk capacitor | Handles slower/larger current transients and stabilizes an entire power rail |
| Ferrite bead | Blocks high-frequency noise while allowing DC power through |
| LC / π filter | Provides stronger power-supply noise filtering than a capacitor alone |
| LDO regulator | Generates a cleaner lower-voltage rail with very little circuitry |
| Buck converter | Efficiently steps DC voltage down |
| Boost converter | Efficiently steps DC voltage up |
| Buck-boost converter | Maintains an output voltage when the input can be either above or below it |
| Load-switch MOSFET | Electronically turns power to an individual subsystem on/off |
| Soft-start circuit | Gradually powers a load to prevent large startup/inrush currents |
| Inrush-current limiter | Prevents large capacitors or loads from drawing a huge instantaneous current when plugged in |
| Power-good circuit | Tells a processor or other subsystem when a power rail has reached a safe voltage |
| Undervoltage Lockout (UVLO) | Prevents circuitry from operating when its supply voltage is too low |
| Power OR-ing | Allows a circuit to operate from either of two power sources without backfeeding one into the other |

**Transistor and Switching**
| | |
| --- | --- |
| H-bridge | Allows current through a motor in either direction, enabling forward/reverse control and braking |
| Low-side MOSFET switch | Lets a small MCU signal control a higher-current load connected to the positive supply |
| High-side MOSFET switch | Switches the positive supply rather than the ground connection |
| BJT transistor switch | Simple way for a low-current signal to control a larger current |
| MOSFET gate resistor | Controls MOSFET switching speed and reduces ringing/EMI |
| MOSFET gate pull-down | Keeps a MOSFET OFF while the MCU is booting or disconnected |
| Gate-driver IC | Provides the large instantaneous current needed to rapidly switch power MOSFETs |
| Bootstrap circuit | Produces the elevated gate voltage needed to drive an N-channel MOSFET on the high side |
| Dead-time circuit/control | Prevents both MOSFETs in a half-bridge from turning on simultaneously and shorting the supply |
| Relay | Allows a low-power electrical signal to switch a higher-voltage/current circuit with galvanic isolation |
| Optocoupler | Transfers a signal using light so two circuits can remain electrically isolated |

**Inductive Load and Motors**
| | |
| --- | --- |
| Flyback diode | Basic inductive-load protection for DC coils |
| TVS flyback clamp | Allows a relay/solenoid coil to discharge faster than with a normal flyback diode |
| RC snubber | Suppresses voltage spikes and ringing caused by switching inductive loads |
| RCD snubber/clamp | Dissipates switching transients in higher-power converters and inductive circuits |
| Motor suppression capacitors | Reduce high-frequency noise generated by brushed motors |
| Freewheeling diode | Provides a current path through an inductive load while switching it with PWM |

**Analog and Sensor Interface**
| | |
| --- | --- |
| RC low-pass filter | Removes high-frequency noise or provides simple anti-alias filtering |
| RC high-pass filter | Blocks DC while allowing higher-frequency AC signals through |
| Op-amp buffer/voltage follower | Prevents one circuit from loading another while preserving the same voltage
| Non-inverting amplifier | Amplifies a signal without reversing its polarity |
| Differential amplifier | Measures the difference between two signals while rejecting common voltage |
| Instrumentation amplifier | Precisely measures very small differential signals, especially from sensors |
| Current-sense resistor/shunt | Converts current into a small measurable voltage |
| Current-sense amplifier | Amplifies the voltage across a shunt resistor for an ADC or control system |
| Virtual ground / midrail reference | Creates an artificial midpoint so bipolar AC signals can be processed from a single supply |
| Precision voltage reference | Provides a more stable reference voltage than an ordinary regulator |
| ADC input RC filter | Reduces noise and provides a local charge reservoir for an ADC's sample-and-hold capacitor |

**Communication Interface**
| | |
| --- | --- |
| I²C pull-up resistors | Required because SDA and SCL use open-drain outputs |
| CAN termination resistor | Typically terminates both ends of a CAN bus to prevent reflections |
| Differential-pair termination | Matches the transmission-line impedance of high-speed differential signals |
| Common-mode choke | Filters common-mode noise on USB, Ethernet, CAN, and similar differential connections |
| USB ESD protection | Protects USB data pins from discharge entering through the connector |
| USB CC resistors | Tell USB-C devices about source/sink roles and connection state |
| RS-485 termination/biasing | Terminates the differential bus while establishing a known idle state |

**Useful Learning Materials**
- https://www.edn.com/category/blog/bogatins-rules-of-thumb/ - Eric Bogatin, Rules of Thumb for Signal Integrity
- https://www.youtube.com/watch?v=ySuUZEjARPY - Rick Hartley, How to Achieve Proper Grounding
- https://www.youtube.com/watch?v=DIMIzKRmync - Eric Bogatin, Breaking Bad Habits in PCB Design
- https://www.youtube.com/watch?v=XumNc480qYo - Robert Feranec, Placement of Decoupling Capacitors
- https://www.youtube.com/watch?v=8i-ftULIjnM - Dr. Ridley, Voltage vs Current Mode for Converters
- https://www.youtube.com/watch?v=oBbTwxt7Sp4 - Dr. Ridley, Freq. Response Measurement Guide
-






---

# Elec Onboarding - Altium Designer Standards

Page ID: elec-onboarding-altium-designer-standards
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=elec-onboarding-altium-designer-standards
Section: electrical
Parent ID: None
Tags:
Owner: Nathan Cunningham
Updated: 2026-09-04T16:02:56.634Z


## Welcome to Electrical Onboarding

At CUPI, we use Altium Designer to develop our PCBs. First, create an account to enroll in a student license by following the instructions at [this link](https://www.altium.com/education/students). You will also eventually need to install Altium Designer on your computer using [this link](https://www.altium.com/documentation/altium-designer/installation-management/installing).

## Altium 365 Library

One helpful way to view past and current projects in a web browser is the Altium 365 Library with [this link](https://jonathan-song.365.altium.com/designs).

![Screenshot 2026-09-04 114826](https://wiki.cornellphysicalintelligence.com/api/context/files/att-cxc5jrn5mtn4zd4v "")

Here, you can also see the current components we have saved to the shared CUPI library:
![Screenshot 2026-09-04 114843](https://wiki.cornellphysicalintelligence.com/api/context/files/att-etpv18s8mtn50ljc "")
Saving components in this way makes it easier for team members in the future to access components we trust, with properly labeled specifications.

## Altium 101

New members will receive training on how to use Altium through instructional workshops, and they will be responsible for their own NME project. Ask a lead for more information.

---

# Electrical Workflow

Page ID: electrical-workflow
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=electrical-workflow
Section: electrical
Parent ID: None
Tags:
Owner: Michael Robbins
Updated: 2026-09-05T01:21:31.955Z

## The V Model
	The V model is an ideal engineering workflow to develop complex systems. The general idea is that planning should always come before design, and a test process should always be applied after a design. Below is a description of each stage and how they relate specifically to PCB design.

![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-wbnz60a4mtndzn69 "")


## Concept of Operations (CONOPS)
This section is the development of a use case of a system. Questions such as “What problem does this solve,” “How is it powered,” “What does it interface with” should all be answered in this section. A complete CONOPS will include a description of a board's intended use, along with a simple system diagram to display how it integrates with other systems or parts of its system. The CONOPS is essentially an argument for why your project should exist, not how your project exists.

## CONOPS Block Diagram Examples
| Example #1 | Example #2|
| --- | --- |
| ![Screenshot 2026-09-04 211355](https://wiki.cornellphysicalintelligence.com/api/context/files/att-bpc9pdh8mtnozh1k "") | ![Screenshot 2026-09-04 211942](https://wiki.cornellphysicalintelligence.com/api/context/files/att-3k1lrcwsmtnp3wkj "")|


## Requirements
After finishing a CONOPS, the general idea and inputs/outputs of your board/system of boards should be realized, but maybe not in depth enough to actually begin selecting components. This moves into the next stage, which is requirement definitions. This section is the basis of your architecture, describing what your design must be able to do.
A common set of requirements will include: Input / Output Voltage, required data outputs, communication interfaces, board dimensions / mounting requirements, operating environment, firmware necessities, important performance targets, etc. This is not a set list, but just a recommendation of what may be needed. The list of requirements will and should change from project to project, as a sensor board performs much different duties than a power board, for example.
## Architecture
This should be one of the longest parts of the PCB design process, as building the correct architecture for a project should make schematic and layout decisions much easier. At this point, your CONOPS and Requirements sections should be essentially locked, and now you’re aiming to figure out how your board/system will take the defined inputs and produce the defined outputs. A good board architecture should include multiple diagrams, IC selection, functional block layouts, and preliminary board designs. It’s okay to utilize EDA tools, like Altium, and sims, like LTSpice, in this stage, but you should not be deep diving into schematic or layout until you have a rigid architecture already defined.
A finished architecture stage will conclude with a **Preliminary Design Review (PDR)**, in which a systems designer will explain their architecture to the rest of the subteam members and be able to answer any questions other members may have. If you don’t feel enough confidence in the system you’ve built to do a PDR yet, then your architecture likely has gaps that you’ve yet to fill in.
## Detailed Design
This section is where schematic / layout are done. At this point, your architecture should be defined enough so that you never ask questions like “well how am I going to get XV here?” or “how am I going to limit the current to X”. Of course, things happen, and you may need to revise your design, but the revisions should be processed and implemented in the architecture section before you implement them in Altium. The most important thing in this section is that you should be revising and catching mistakes as you go, as checking an entire board is much more difficult than checking sub-sections at a time. Make valid uses of design check tools, such as ERC and DRC, along with reviewing the Design Heuristics section of this page throughout the board development process. While other members are always here to assist, you shouldn’t rely on leads or other members to catch mistakes for you, since you know your board best. Finishing this section means a clean ERC and DRC with a reviewed board that matches all requirements and CONOP expectations.
In this section, you should also begin planning for tests to validate your board.
## Implementation
The implementation stage is where the detailed design becomes physical hardware. Before ordering anything, the Detailed Design stage should conclude with a **Critical Design Review (CDR)**. During the CDR, the designer should demonstrate that the schematic and layout satisfy the architecture, requirements, and CONOPS. All major ERC and DRC violations should be resolved, component availability should be checked, and the final manufacturing files should be reviewed by someone other than the primary designer. Once the design passes its CDR, the schematic and layout should be treated as frozen unless a discovered problem requires a documented revision.
After the CDR, the designer will generate the files required to fabricate and assemble the board. These commonly include Gerber or ODB++ files, drill files, a bill of materials, pick-and-place data, schematic PDFs, and assembly drawings. These files should be inspected before being sent to a manufacturer, since a clean DRC does not guarantee that the exported files are correct. When the board arrives, it should be visually inspected for fabrication defects before assembly. Following assembly, verify component values, polarity, orientation, and solder quality before applying power. Any substitutions, rework, or deviations from the released design should be recorded.
## Test, Verification, and Validation
Once the board has been assembled, testing should begin with a written bring-up procedure rather than immediately attempting full system operation. Visually inspect the board, verify component orientation and polarity, and measure resistance between each power rail and ground before applying power. Initial power-up should use a current-limited supply while monitoring current, rail voltages, and component temperatures. After confirming that the power system is safe, test each functional block individually, including regulators, clocks, reset signals, programming interfaces, communication buses, sensors, and output drivers. Loads should be connected gradually, and all measurements, failures, rework, and design changes should be documented. The board is ready for system integration once its individual circuits operate as intended and any significant problems have been resolved or understood.
After individual testing, integrate the board into the complete system and compare its operation against the Requirements and CONOPS. Verification determines whether the completed design satisfies its documented requirements through inspection, measurement, demonstration, or testing. Validation determines whether the board fulfills its intended purpose under realistic operating conditions using the actual power sources, cables, loads, firmware, and surrounding hardware. Put simply, verification asks, “Did we build the board correctly?” while validation asks, “Did we build the correct board?” If a test fails, determine which earlier stage of the V workflow must be revised, implement the correction there, and carry the change forward through the remaining stages.




---

# Mech Onboarding - Onshape Part Standards

Page ID: mech-onboarding-onshape-part-standards
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=mech-onboarding-onshape-part-standards
Section: mechanical
Parent ID: None
Tags:
Owner: Andre Boufama
Updated: 2026-09-10T18:44:49.436Z

## Custom Part Creation
Every part must be named, and have a material assigned to it. It is easy to check if an assembly's parts follow this standard by doing a weight analysis on the whole assembly and seeing if there are any errors.

Parts are all based on sketches; just like the parts, sketches have their own set of standards.

## Sketches
**Naming is not required for sketches, but for larger more complex parts, it might be helpful to name some of the driving sketches.** All sketches should be properly defined. A sketch that is not defined shows up in blue in the Onshape Sidebar, and all undefined elements show up in blue in the sketch.

When making sketches, try to design constraints in an intelligent way that allows for easy changing of dimensions in the future. Also be conscious of what surface a sketch is defined on; if you expect a surface to be modified or change a lot, putting a sketch there will cause a lot of annoying work down the line.

BAD SKETCH: ![Screenshot 2026-09-10 at 2.39.08 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-e33ryezgmtvvfrxw "")

BETTER SKETCH:
![Screenshot 2026-09-10 at 2.39.04 PM](https://wiki.cornellphysicalintelligence.com/api/context/files/att-pyqcynj2mtvvhzmi "")


## Assemblies

All subassemblies and assemblies should be mated to the origin. A good way to check a assembly is properly mated is to drag select over all the parts and try to translate the whole selection. If there are any parts without defined relationships, they will be dragged and visible.


## Creating Screw Holes
Screw holes must be made with the hole tool on a sketch point. When making clearance holes, use the "close" standard unless there is good reason not to.



---

# HEXAPOD MKII

Page ID: hexapod-mkii
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=hexapod-mkii
Section: projects
Parent ID: None
Tags:
Owner: Andre Boufama
Updated: 2026-09-30T02:47:02.995Z

## Rendered
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-axk4xh6smtzdqbeq "")

## Electrical Architecture
![IMG_7703](https://wiki.cornellphysicalintelligence.com/api/context/files/att-1lmbsq37mum3rh04 "")

This some documentation regarding the thought process and design behind the MKII Hexapod project.

The Hexapod MKII project continues on trying to make an autonomous walking robot, but scales up the ambitions we had during the first iteration.

The robot weighs in the 5-10kg range, uses QDD (quasi direct drive) motors on each leg, and carries a powerful edge computer.

**This is where all the CAD lives: **https://cupi.onshape.com/documents/881b01051a1ec5c958bf7768/w/56fa9ce49a9ab26a61a9abc5/e/82f230292d85a82bc65783fd










---

# Links

Page ID: sponsor-outreach-tracker
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=sponsor-outreach-tracker
Section: operations
Parent ID: None
Tags:
Owner: Luke Evans
Updated: 2026-11-20T23:12:27.982Z

[CUPI_Sponsor_Tracker_Artifact](https://claude.ai/artifact/QRx6szzE7MTj7J1aGXmRXW#sheet-sht_dtpv5br852.2)

[Resume_Book_Link](https://drive.google.com/drive/folders/1OGjVOiZNh4PdTDlfe8Y6GTrGqv50plkL?usp=drive_link)

!file[CUPI Sponsorship Packet](https://wiki.cornellphysicalintelligence.com/api/context/files/att-fc00f28440fd3dc55c7485d6ce0861e2)


---

# USB-to-CAN PCB

Page ID: can-board-v1
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=can-board-v1
Section: electrical
Parent ID: None
Tags:
Owner: Mina Yeh
Updated: 2026-11-10T17:04:19.260Z

**Part:** CUPI - HEXAPOD - USB-to-CAN
**Rev:** V2
**Owner:** Mina Yeh
**Status:** Completed

Takes USB-C input from the Jetson t5000 and converts to three FDCAN buses.

## Requirements

- Input: USB-C data & 5V power from the Jetson Nano
- Output: 6 JST-PH 2.54mm plugs (CAN_H & CAN_L) (Three separate buses.)
- Dimensions: 52.58 mm x 43.18 mm
- M2.5 Mounting Points

## Design V2
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-w3t535tamw9xhfnm "")
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-br44k4i2mw9xk8f0 "")
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-60zgijjqmw9xhvs9 "")
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-nb4y1vg3mwaxwb0q "")
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-2ai6x2cgmw8fiecg "")

## Design V1
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-o86l4r16mw9xw6tu "")
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-9nzsbkb2mw9xzkuj "")


## Notes
![image](https://wiki.cornellphysicalintelligence.com/api/context/files/att-zstaz4hkmvpzbx1q "")
https://jlcpcb.com/pcb-impedance-calculator
Length tolerances are within 1mm.


---

# Elec Reference - FPGA, Verilog, & Vivado Guide

Page ID: elec-reference-fpga-verilog-vivado-guide
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=elec-reference-fpga-verilog-vivado-guide
Section: electrical
Parent ID: None
Tags:
Owner: Nathan Cunningham
Updated: 2026-11-02T21:45:24.107Z

::: tip How to Use this Document
Reference this document while writing Verilog in VS Code and for further deployment using Vivado

This document is also an installation guide for new members.
:::

## Background Knowledge

**Verilog** is a hardware description language (HDL) used to describe and design digital hardware. Unlike traditional programming languages, which typically describe instructions executed by a processor, synthesizable Verilog describes circuits that can operate concurrently. You will write Verilog in **VS Code** and create testbenches to verify that your hardware behaves as expected.

**Verilator** is a tool used to analyze, lint, and simulate Verilog designs. **Icarus Verilog** is a compiler and simulator used to run Verilog testbenches. Linting involves analyzing source code to identify potential problems, such as syntax errors, unintended latches, and signal-width mismatches.

**Vivado** is AMD's FPGA design software. It synthesizes Verilog into digital hardware, performs placement and routing, checks timing, and generates a bitstream that can configure the FPGA.

**Field-programmable gate arrays** (FPGAs) are integrated circuits whose digital hardware can be reconfigured after manufacturing. They contain programmable logic resources, including lookup tables (LUTs), flip-flops, and configurable routing connections. LUTs implement logic functions by storing their truth tables in small programmable memories. Many FPGAs also contain dedicated hardware resources, such as block RAM, DSP units, and high-speed interfaces.


## Installations & Setup

* Get VS Code with this [Link](https://code.visualstudio.com/download).
* Get Git with this [Link](https://git-scm.com/install/).
* Create a GitHub account if you do not already have one: [Link](https://github.com/).
* Here is the link to the shared repository on GitHub: [GitHub - vincent-yeet/hexapod-fpga](https://github.com/vincent-yeet/hexapod-fpga). If you currently do not have access, ask Vincent to add you as a collaborator.

---

**Next:**
1. Copy the link to the repository.
2. Open VS Code
3. Press Ctrl + Shift + P to open the Command Palette.
4. Type *Git: Clone* and press Enter.
5. Paste the repository URL and press Enter.
6. Choose a local folder and click Open after cloning.
7. If you are not already signed into GitHub, do so now.
8. Review the [README.md](https://github.com/vincent-yeet/hexapod-fpga/blob/main/README.md) and [CONTRIBUTING.md](https://github.com/vincent-yeet/hexapod-fpga/blob/main/CONTRIBUTING.md) files for how to operate in the shared repository.

---

Open **Vivado** by clicking this [Link](https://www.amd.com/en.html).
1. Click on the person icon in the top right and click Create Account.
2. Enter your Cornell email and other information.
3. After setting up your account, follow this [Link](https://www.amd.com/en/products/software/adaptive-socs-and-fpgas/vivado.html) to the downloads page.
4. Click Download, scroll down, and click the link under Title.
5. Enter your address, set your job function to Student, and click Download.
6. Obtain a free BASIC license from the AMD Vivado licensing page: [Link](https://www.amd.com/en/products/software/adaptive-socs-and-fpgas/vivado/vivado-buy.html)
7. Select the checkbox for Vivado Basic Tier License, Node Locked License.
8. Click Select a Host, then Add a Host, and add your Host Name and OS.
9. In Command Prompt, run *ipconfig /all* and find the Physical Address under the Wireless LAN adapter Wi-Fi section.
10. Select Ethernet MAC and add the Physical Address value in the Host ID Value section.
11. You should now see this information added under the Manage Licenses tab.
12. You can now run the .exe file. During installation, select Vivado.
13. Under Devices, expand the SoCs dropdown and click Zynq-7000 All Programmable SoC. Also make sure both Installation Options are checked.
14. After installation (takes a long time), follow the instructions in the email from when you created your license.


## Creating a Branch and Pushing Changes in VS Code

Create a new branch:
1. Open VS Code and make sure you are in the repository folder
2. In the terminal, run:
~~~
git switch main
git pull origin main
~~~
3. Click the text that says *main* on the bottom left.
4. Select Create a new branch.
5. Enter a descriptive but concise name for your branch and press Enter.

---

Add or modify files (skip to step 4 if modifying files):
1. Open the Explorer panel on the left.
2. Right-click the folder and select New File.
3. Enter a descriptive but concise name for the file.
4. Make your changes and save using Ctrl + S.
5. Don’t forget test cases, as you should push them together.
6. See below for how to run the linter and test cases.

---

Stage and commit the changes. Note: Finish linting and testing before committing changes.
1. Open the terminal and make sure you are in the working directory.
2. Type the following and press Enter.
~~~
git add .
~~~
3. Type the following and press Enter, making your commit message descriptive but concise.
~~~
git commit -m “Commit Message”
~~~
4. Type the following and press Enter, changing Branch Name to the actual name of the new branch.
~~~
git push -u origin Branch Name
~~~
5. After the first push, you can just run:
~~~
git push
~~~

---

Create a pull request:
1. Click *Compare & pull request* after pushing your branch.
2. Ensure the base branch is *main* and the compare branch is the new branch.
3. Enter a descriptive title and explanation of your changes.
4. Click *Create pull request*.

## Linter and Test Cases
Once you finish a Verilog file in VS Code, you need to lint the hardware design to check for potential problems.

To do so, run the following in the correct directory, where File Name should be replaced with the actual name of the new or modified file.
~~~
verilator -Wall --lint-only src/rtl/common/ModuleName.sv
~~~

To compile and simulate the testbench, run:
~~~
iverilog -Wall -g2012 -s TestbenchModule -o test.vvp src/rtl/common/ModuleName.sv verification/unit/TestbenchFile.sv
~~~
Then:
~~~
vvp test.vvp
~~~


---


**Note:** Once CUPI leads create a **Makefile**, these commands will simplify significantly.

For example:
~~~
make lint
make test
~~~

## Vivado

1. Create or open a Vivado project. Select the correct FPGA device or board definition.
2. Add Verilog source files. Specify the top-level hardware module.
3. Add constraints. Define the relevant clocks, pin assignments, and other timing or electrical constraints.
4. Run synthesis. Convert RTL into an FPGA logic netlist and inspect warnings.
5. Run implementation. Place and route the design, then examine timing results.
6. Generate the bitstream. Produce the configuration file for the FPGA.
7. Program the hardware. Connect the board, open Hardware Manager, and program the device.
8. Test the physical design. Verify its behavior on the board, rather than relying solely on simulation.


---

# Elec Reference - Differential Signaling in Altium

Page ID: elec-reference-differential-signaling-in-altium
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=elec-reference-differential-signaling-in-altium
Section: electrical
Parent ID: None
Tags:
Owner: Nathan Cunningham
Updated: 2026-11-09T05:24:58.831Z

## Background
**Differential signaling** is a way to transmit data using a pair of complementary traces that carry equal-magnitude but opposite-polarity voltages. So, the receiving circuit measures the voltage difference between the two wires, instead of measuring a single wire’s voltage against a shared ground reference.

Differential signalling is important because it prevents noise through **common-mode rejection**. Since the two conductors are routed tightly parallel to one another, any incoming external electromagnetic interference or crosstalk hits both wires equally. Consequently, the noise is canceled out when the receiving circuit takes their voltage difference.

When using differential routing, the pair maintains a consistent differential impedance along the entire length of the traces, as the width and the gap between the two traces must stay uniform throughout the route.

**IMPORTANT:** Always route differential signals over a continuous, solid reference plane, usually ground, without splitting the return path underneath the pair.

---

**Which signals need differential routing?**

- High-Speed Serial: USB (D+/D-), HDMI, PCIe, DisplayPort, SATA, and MIPI
- Network/ Communication Busses: CAN, Ethernet, and RS-485/ RS-422

## Step 1 - Label Differential Pair on Schematic

When adding your differential pair in the schematic design phase, the naming of the nets should always follow the following standard:
- The two nets have the same leading characters, like "USB_D"
- The negative net ends in _N and the positive net ends in _P

This is important so the software can automatically recognize these two nets as a differential pair during design synchronization and routing.

After naming the nets with this standard, you must add the Differential Pair symbol (called a directive) to both of these nets. Altium reads these symbols and automatically creates the pair when you compile and push the design to the PCB.

![Screenshot 2026-11-06 165007](https://wiki.cornellphysicalintelligence.com/api/context/files/att-quo33snymw5id5g8 "")
![Screenshot 2026-11-06 164631](https://wiki.cornellphysicalintelligence.com/api/context/files/att-9s04g59fmw5i9yru "")

## Step 2 - PCB Panel

With the PCB document open, open up the PCB panel.
1. From the top dropdown, open the Differential Pairs Editor
2. Click Add.
3. Enter the net names.
![Screenshot 2026-11-08 230537](https://wiki.cornellphysicalintelligence.com/api/context/files/att-cf5tdpybmw8qqrlx "")

## Step 3 - Layer Stack Manager

From the Design tab of the top ribbon, open the Layer Stack Manager.

First: Make sure the stakup layer thicknesses are appropriately set.

1. On the bottom left, click the Impedance tab
2. Click Add Impedance Profile
3. Click here:
![Screenshot 2026-11-08 231631](https://wiki.cornellphysicalintelligence.com/api/context/files/att-bi6zu2x0mw8r1s52 "")
4. Type the net name (without _N or _P) in the Description section
5. In the Type dropdown, select Differential
6. Set the Target Impedance to the standard impedance for the desired communication protocol. For example, USB 2.0: 90Ω
7. Scroll down to the Transmission Line section and change the Width and Trace Gap parameters until the impedance reaches your desired value. Make sure the two Widths are the same and are at least 6 mils and the Trace Gap is at least 6 mils.
![Screenshot 2026-11-08 232618](https://wiki.cornellphysicalintelligence.com/api/context/files/att-7o8mldkbmw8rh8ue "")

## Step 4 - Rules

Now that you have created the Impedance Profile for the differential pair, go back to the PCB document and open Rules from the Desgn tab.
1. Navigate to Default Rule Set/ Routing / Differential Pairs Routing
2. Right click Differential Pairs Routing and select Add Rule
3. Select Diff Pair and select the differential pair net from the dropdown.
4. Check the box for Use Impedance Profile and make sure it aligns with the name you created for the Impedance Profile in the Layer Stack Manager.
5. Also ensure that the Max Width and Max Gap are the same as what you set in the Layer Stack Manager.
![Screenshot 2026-11-08 233906](https://wiki.cornellphysicalintelligence.com/api/context/files/att-dwu9d2hrmw8rv52g "")


---

# Elec Reference - Gerber Files

Page ID: elec-reference-gerber-files
Source: https://wiki.cornellphysicalintelligence.com/llms-full.txt?page=elec-reference-gerber-files
Section: electrical
Parent ID: None
Tags:
Owner: Nathan Cunningham
Updated: 2026-11-15T18:04:58.998Z

::: tip How to Use This Document
Reference this document when you are fully done with the schematic and layout design for your PCB in Altium and want to order the board on JLCPCB.
:::

## What are Gerber Files?

**Gerber files** are the industry-standard blueprint for manufacturing printed circuit boards. They translate digital CAD layouts into physical instructions for photoplotters, laser direct imaging, and CNC machines.

These are the files that you will need when ordering your board on **JLCPCB**.

## Step 1 - Create the BOM

The **BOM**, or Bill of Materials, is a list of all the components required to manufacture the PCB, which includes the name, designator, quantity, and manufacturer of each component, among other descriptive information.

To create the BOM, right-click on the project name in the Projects panel, click Add New to Project, and click Active BOM.

Creating the BOM in advance is useful because it allows you to revise which components you are using if any appear to be unavailable, out of stock, or missing crucial information on the BOM.

## Step 2 - Create an Output Job File

The **Output Job** is the file in Altium that will export all necessary Gerber information to your local file system.

1. Right-click on the Output Container named Video and select Delete
2. Click Add New Assembly Output under Assembly Outputs, and navigate to Generate Pick and Place Files > (Project_name.PcbDoc)
3. Right-click on Generate Pick and Place Files and select Configure. Under Formats, make sure CSV is selected, Text is unselected, and click Okay
![Screenshot 2026-11-15 125007](https://wiki.cornellphysicalintelligence.com/api/context/files/att-tmdwl2dfmwi4r55t "")

4. Click Add New Fabrication Output under Fabrication Outputs, and navigate to Gerber Files > (Project_name.PcbDoc)
5. Right-click on Gerber Files and select Configure. Make sure all checkboxes are checked on the right side, and click Apply. The left side of Gerber Setup should look like this:
![Screenshot 2026-11-15 124833](https://wiki.cornellphysicalintelligence.com/api/context/files/att-bnffzj39mwi4p0sn "")

6. Click Add New Fabrication Output under Fabrication Outputs, and navigate to NC Drill Files > (Project_name.PcbDoc)
7. Right-click on NC Drill Files and select Configure. Use the following parameters:
![Screenshot 2026-11-15 124656](https://wiki.cornellphysicalintelligence.com/api/context/files/att-la44zv5zmwi4phqk "")

8. Click Add New Report Output under Report Outputs, and navigate to Bill of Materials > (ActiveBOM_file_name)
9. Right-click on Bill of Materials and select Configure. Ensure the File Format is set to MS-Excel (*.xls, *.xlsx, *.xlsm) and click Okay. Check the Open Exported checkbox if you want to verify that the Excel file is correct
![Screenshot 2026-11-15 125108](https://wiki.cornellphysicalintelligence.com/api/context/files/att-wuqqzew1mwi4skx8 "")

10. Click the circles on the right of each of the three new files you just added to enable them. You should see green lines that point to Folder Structure
11. Under Folder Structure, click Generate
12. Close the pop-up files in Altium until you get to the .csv file. You should see the path of where the project output documents are located in your local file system. Copy the path to the general folder, called Project Outputs for <Project_Name> or similar, and open it by pasting it into File Explorer
13. Copy the files in the NC Drill folder and paste them into the folder named Gerber. Right-click on the Gerber folder and select Compress To > ZIP File
14. If your Excel file didn't open when generating the files, go back to the Output Job page. Right-click on Bill of Materials and select Configure. Click Export and ensure the Excel file is placed in the same general folder

## Step 3 - JLCPCB

Go to the [JLCPCB website](https://jlcpcb.com/) and click Order Now.

1. Click Add Gerber File, paste in your copied path, and select the zipped Gerber folder from before. If you do not see the 3D view of your board with the correct number of Layers and correct Dimensions, you most likely missed an instruction above.
![Screenshot 2026-11-09 163335](https://wiki.cornellphysicalintelligence.com/api/context/files/att-aib0lhjdmw9s3c9u "")
2. Under High-spec Options, set the Via Covering to Untented. This lets us probe the vias if needed.
![Screenshot 2026-11-09 163441](https://wiki.cornellphysicalintelligence.com/api/context/files/att-joclrkd7mw9s4q70 "")
3. Scroll down and toggle the slider for PCB Assembly on. Ask the leads if you should set the PCBA Qty to 5 or 2
4. Click Next twice and upload your BOM and CPL (pick and place) files using the same file path. Click Process BOM & CPL
5. In the Parts Selection section, ensure that all components are checked and have the correct footprint and price. This is extremely important. If you decide to uncheck a component from this list because you intend to buy it from DigiKey, you will need to solder it yourself after receiving the board. If any components are unavailable on JLCPCB, you will likely have to go back to find a compatible component in Altium before restarting the whole process.
6. In the Component Placement section, click on each IC or polarized component and press space until they are aligned correctly. Use the orientation marker (usually a dot near pin 1) and the +/- indicators, if applicable, to orient them properly. Make sure all components are oriented correctly.
![Screenshot 2026-11-14 120457](https://wiki.cornellphysicalintelligence.com/api/context/files/att-zt6onov9mwi58ort "")


After these steps, you should be ready to add the order to the cart.

---

See [How do I place a PCBA order?](https://jlcpcb.com/help/article/how-do-i-place-a-pcba-order) for more information.


---

End of context.
